Montpelier II Cast Iron Wood Insert in Black
Free Freight Shipping!
The Montpelier II wood insert from Vermont Castings gives you an ideal view of a gently burning fire, contained within a lovingly crafted cast-iron structure. If you’ve ever wanted to turn ... Read More
Call 866-327-1447
- Description
- Specifications
- Dimensions
- Downloads
- Venting Notes
The Montpelier II wood insert from Vermont Castings gives you an ideal view of a gently burning fire, contained within a lovingly crafted cast-iron structure. If you’ve ever wanted to turn your old, drafty fireplace into a beautiful centerpiece that can enliven the room all year round, you can’t go wrong with the timeless elegance of the Montpelier II. Enjoy the benefits of Vermont Castings’ precise designs and unsurpassed attention to derail.
Features
- Heats 1,000-2,400 sq. ft. with 56,000 BTUs, based on climate and home efficiency
- Burns up to 20” logs
- Timeless cast-iron styling with a furniture-quality finish
- Variable speed fan efficiently distributes heat throughout the ro
MONTPELIER II WOOD INSERT
| Appliance Width: | 31-1/2" |
| Appliance Height: | 23-1/8" |
| Appliance Depth1 | 17-5/8" |
| Front Width Minimum Firebox Opening | 32" |
| Height Minimum Firebox Opening | 23-3/8 |
| Depth Minimum Firebox Opening: | 17-7/8" |
| Back Width Minimum Firebox Opening: | Wood |
| Peak BTU/hr Output2 | 56,000 |
| Heating Capacity3 | 1,000 - 2,400 sq. ft. |
| Maximum Burn Time | 7 hrs. |
| Firebox Capacity: | 2.4 |
| Recommended Log Lengt | 20" |
| Efficiency5: | LHV 77%, HHV 71% |
| Emissions: | 1.9 grams/hour |
| 1. | Appliance Depth is based on dimensions of the entire unit including depth of firebox and extension onto hearth. |
| 2. | BTU: 1st hour output uses the high burn efficiency number. Actual BTU will vary depending on the type of fuel used and its moisture content. |
| 3. | Consult with your dealer for help in determining the product that best suits your heating needs based on factors such as local climate, home efficiency, the location of the heater, and air movement in the room. |
| 4. | Actual burn times will vary based on operating conditions, including load size, moisture content, and type of wood used, as well as installation environment. |
| 5. | Weighted average LHV (Low Heating Value) & HHV (High Heating Value) efficiencies using data collected during EPA emissions test. HHV efficiency over 75% qualifies for the 2021-2023 Federal Tax Credit. |
Heat output will vary depending on the type of fuel used. Actual product appearance, including flame, may differ from the image depicted above. Appearance of the flame and ember may vary based on the type of fuel and venting configuration. Product specifications and pricing subject to change without notice. Refer to the owner's manual for complete clearance requirements and specifications. For testing and listing information please refer to the owner's/installation manual.
*Heating capacity to be used as a guide only. Ask for help in determining which product best suits your heating needs based on climate and home efficiency.
Front View
Side View
Top View
Minimum Fireplace Opening
Basic Clearances (front mount)
Brochures
- https://downloads.hearthnhome.com/brochures/VMT_1012_Broc_WoodInserts.pdf
- https://downloads.hearthnhome.com/brochures/VMT-1012C_WoodInserts_fr_brochure.pdf
Installation Guides
- https://downloads.hearthnhome.com/installManuals/MONTPELIER_II_WOOD_INSERT_INSTALLATION_7101_802.pdf
- https://downloads.hearthnhome.com/installManuals/Translations/MONTPELIER_II_WOOD_INS_INSTALLATION_FRENCH_CANADIAN_FC7101_802.pdf
Manuals
- https://downloads.hearthnhome.com/installManuals/MONTPELIER_II_WOOD_INSERT_OWNERS_7101_803.pdf
- https://downloads.hearthnhome.com/installManuals/Translations/MONTPELIER_II_WOOD_INS_OWNERS_FRENCH_CANADIAN_FC7101_803.pdf
